5-4 Chapter 5: RAID conguration
5.1.3 Setting the RAID item in BIOS
You must enable the RAID function in the BIOS Setup before creating RAID set(s)
using SATA HDDs. To do this:
1. Enter the BIOS Setup during POST.
2. Go to the Main menu > Storage Conguration, and then press <Enter>.
3. Set the Congure SATA as item to [RAID].
4. Save your changes, and then exit the BIOS Setup.
Refer to Chapter 4 for details on entering and navigating through the BIOS
Setup.
Due to chipset limitation, when set any of SATA ports to RAID mode, all SATA
ports run at RAID mode together.
5.1.2 Installing hard disk drives
The motherboard supports Serial ATA hard disk drives. For optimal performance,
install identical drives of the same model and capacity when creating a disk array.
To install the SATA hard disks for a RAID conguration:
1. Install the SATA hard disks into the drive bays.
2. Connect the SATA signal cables.
3. Connect a SATA power cable to the power connector on each drive.
