ASUS P7F-M WS 4-29
4.5 Power menu
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Advanced Power Boot Tools Exit
EuP [Disabled]
APM Conguration
Hardware Monitor
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Include ACPI APIC
table pointer to
RSDT pointer list.
4.5.1 EuP Ready [Disabled]
[Disabled] Disables the Energy Using Products (EuP) Ready function.
[Enabled] Allows BIOS to switch off some power at S5 state to get system
ready for the EuP requirement. When set to [Enabled], power for
WOL, WO_USB, audio and onboard LEDs will be switched off at
S5 state.
4.5.2 APM Conguration
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
APM Conguration
Restore on AC Power Loss [Last State]
Power On By RTC Alarm [Disabled]
Power On By External Modems [Disalbed]
Power On By PCI Devices [Disabled]
Power On By PCIE Devices [Disabled]
Power On By PS/2 Keyboard [Disabled] PS/2 Keyboard [Disabled]
Power On By PS/2 Mouse [Disabled] PS/2 Mouse [Disabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
BIOS SETUP UTILITY
Power
<Enter> to select
whether or not to
restart the system
after AC power loss.
Restore On AC Power Loss [Last State]
[Power Off] The system goes into off state after an AC power loss.
[Power On] The system goes into on state after an AC power loss.
[Last State] The system goes into either off or on state, whatever the system
state was before the AC power loss.
