5-10 Chapter 5: RAID conguration
5.2.4 Resetting disks to Non-RAID
Take caution before you reset a RAID volume hard disk drive to non-RAID.
Resetting a RAID volume hard disk drive deletes all internal RAID structure on
the drive.
To reset a RAID set hard disk drive
1. From the utility main menu, select
3. Reset Disks to Non-RAID
and press
<Enter>. The following screen appears.
2. Use the up/down arrow key to select the RAID set drive(s) you want to reset,
and then press <Space> to select.
3. Press <Enter> to reset the RAID set drive(s). A conrmation message
appears.
4. Press <Y> to reset the drive(s) or press <N> to return to the utility main
menu.
Resetting RAID disk will remove its RAID structures
and revert it to a non-RAID disk.
WARNING: Resetting a disk causes all data on the disk to be lost.
(This does not apply to Recovery volumes)
Port Drive Model Serial # Size Status
0 ST3160812AS 9LS0HJA4 149.0GB Member Disk
1 ST3160812AS 9LS0F4HL 149.0GB Member Disk
Select the disks that should be reset.
[
↑↓
]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete
[ RESET RAID DATA ]
