Accessories

BIOS

Manageability

Support Disc

Operating System

Form Factor

Note

1 x 8-pin ATX 12V Power connector(s)

1 x EZ XMP switch

1 x Front panel connector(s)

1 x System panel(s) (Q-Connector)

1 x DRCT header(s)

1 x MemOK! button(s)

1 x Thermal sensor connector(s)

1 x TPU switch(es)

1 x CPU/DRAM overvoltage jumper(s)

1 x Power-on button(s)

1 x Reset button(s)

1 x Clear CMOS button(s)

1 x Dr.Power switch(es)

1 x 3-pin CHASSIS(Chassis intrusion) connector

User's manual

ASUS Q-Shield

1 x COM port cable(s)

12 x SATA 6Gb/s cable(s)

1 x 3-Way SLI bridge(s)

1 x 4-Way SLI bridge(s)

1 x Q-connector(s) (2 in 1)

1 x 2-port USB 2.0 module(s)

128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS

2.7, ACPI 5.0, Multi-language BIOS,

ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan

Control, F3 My Favorites, Quick Note, Last Modified log,

F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial

Presence Detect) memory information.

WfM 2.0, DMI 2.7, WOL by PME, PXE

Drivers、ASUS Utilities、EZ Update 、Anti-virus software (OEM

version)

Windows® 8.1 32/64-bit

Windows® 8 32/64-bit

Windows® 7 32/64-bit

CEB Form Factor

12 inch x 10.5 inch ( 30.5 cm x 26.7 cm )

*1 When installing Intel® Socket 2011-v3 Core™ i7 Processors
