Storage

LAN

Audio

USB Ports

x16/x16/x16 or quad x16/x16/x16/x16 or seven x16/x8/x8/x8

/x8/x8/x8)

Intel® X99 chipset : *

1 x SATA Express port, gray, compatible with 2 x SATA 6.0 Gb/s

ports

1 x M.2 x4 Socket 3, gray, , with M Key, type 2260/2280 storage

devices support (PCIE mode)

8 x SATA 6Gb/s port(s), gray, *

Intel® Rapid Storage Technology supports*

ASMedia® SATA Express controller : *

1 x SATA Express port, gray, compatible with 2 x SATA 6.0 Gb/s

ports

ASMedia® SATA 6Gb/s controller :

2 x eSATA 6Gb/s port(s)compatible with 2 x SATA 6.0 Gb/s ports

Intel® I210-AT, 1 x Gigabit LAN Controller(s)

Intel® I218LM, 1 x Gigabit LAN, Dual interconnect between the

Integrated Media Access Controller (MAC) and Physical Layer (PHY)

Realtek® ALC1150 8-Channel High Definition Audio CODEC

featuring Crystal Sound 2

- Supports : Jack-detection, Multi-streaming, Front Panel

Jack-retasking, Front Panel MIC Jack-retasking

- High quality 109 dB SNR stereo playback output (Line-out at rear)

and 104 dB SNR stereo playback input (Line-in)

- High-fidelity audio OP AMP(s)

Audio Feature :

- DTS Ultra PC II

- DTS Connect

- Optical S/PDIF out port(s) at back panel

- BD Audio Layer Content Protection

- Audio Shielding: Ensures precision analog/digital separation and

greatly reduced multi-lateral interference

- Dedicated audio PCB layers: Separate layers for left and right

channels to guard the quality of the sensitive audio signals

- Audio amplifier: Provides the highest-quality sound for

headphone and speakers

Premium Japanese-made 12K hours capacitors

- Absolute Pitch 192khz/24bit true BD lossless sound

Separate layer for left and right track, ensuring both sound deliver

equal quality

Intel® X99 chipset :

4 x USB 3.0/2.0 port(s) (4 at back panel, , 4 at mid-board)

Servers & Workstations - X99-E WS - ASUS

http://www.asus.com/Commercial_Servers_Workstations/X99E_WS/s...

2 von 7 26.11.2014 13:59
